Bronze Gate Valve (GGV)

Specification

MSS SP-110
SCREWED BODY CAP • FULL BORE
BLOW-OUT PROOF STEM • PTFE SEAT
THREADED TO BS 21 (ISO7) / ASME B1.20.1 OR NPT

Download

For a comprehensive overview of the product specifications mentioned above, feel free to download the product catalog here.

Category:

Materials

PartMaterialASTM
BodyBronzeC83600
BonnetBronze (size 15A ~ 25A)
Brass (size 32A ~ 100A)		C83600
C37700
DiscBronzeC83600
StemBrassC37700
PackingPTFE
Packing NutBrassC36000
GlandBrassC36000
HandleAluminium

Note: Design and specifications are subject to change without prior notice.

Pressure Ratings

Working Pressure25 bar C.W.P.
10.3 bar Saturated Steam
Testing PressureShell: 37.5 bar Hydrostatic
Seat: 27.5 bar Hydrostatic
80 psi (5.5 bar) Air
Working Temperature-10°C ~180°C
Suitable MediaWater & Oil

Structure

Dimensions

SizeLHD
mminchmminchmminch
1548.01.972.52.960.02.4
2050.52.084.53.270.02.8
2559.52.399.03.970.02.8
3265.52.6117.04.680.03.2
4070.52.8131.05.290.03.5
5075.02.9164.06.5100.04.0
6599.53.9189.07.4119.04.7
80108.04.3227.08.9140.05.5
100121.04.8268.010.6140.05.5
